NOTE: renderings above may or may not show the actual welding points included in all of our truss products. Smartstage strongly recommends that you engage the services of a licensed engineering professional to analyze complex loading configurations and/or conditions.
SKU | TRB1201S / TRB1202S / TRB1203S / TRB1204S / TRB1205S / TRB1206S / TRB1208S / TRB1210S |
CSI | 11 61 00 |
Size | 12″ x 12” (30.48 cm x 30.48 cm) |
Length | 1’ - 8’, and 10’ (30.48 cm - 304.8 cm) |
Diagonal tube | 1" x 0.125" (25 mm x 3.124 mm) |
Weight | 14 - 62 lbs (6.35 kg - 28.12 kg) |
Box shape | Four round tubes OD of 2″ (50.8 mm) |
Material | Welded to TUV standards 6061-T6 alloy |
Finish | Natural aluminum |
Coating | (optional) powder coating |
Certification | TUV & SGS certified (load tested & inspected) |
Compatibility | Compatible with all other 12″ truss |
Components | Truss bolts sets available |
Fast and simple bolt-together aluminum Lego-like blocks. Whatever you imagine you can build. Smartstage truss can run in ANY direction at ANY length desired allows you to build multi truss blocks covers bridges grids artistic structures. Smartstage trusses configure fast and easily. Simply draw your dream and assemble the sections 4 bolts each end in the configuration of your desire. The structure will always remain rigid and strong. Smartstage box truss 12″ x 12″ silver aluminum bolt connection is designed and engineered with life-dependable welds to perform to the highest standards. TUV & SGS certified worldwide load tested and x-rayed for quality assurance. Smartstage 12-inch box truss/lighting truss comes in multiple sizes for lighting show performances and multiple applications. Smartstage lighting truss is easy to install with integral design simple bolt style connection comes in multiple lengths from 1′ to 10′ with numerous accessories wedges hinges and corner blocks. Smart trusses are in many lengths and finish curved and angled with a wide range of connection hardware. Smart trusses can be configured to fulfill any creative structural concept you design for your event venue or tour.
